BLOCK-CP 15 Ts

Block Ice Machines

ABOUT PRODUCT

Termodizayn block ice machines have an easy to use, dynamic and intelligent design compared to others. It generates ice blocks by pressing and shaping the ice which is produced by the flake ice machine.
- Clean & Hygienic
- Fast & User Friendly
- No Moulds & No Glycol
- 24/7 non-stop operation.
- New Design & Latest Ice Production Technology
- Produces blocks of consistent size, shape, and weights. - Gives you the flexibility to use it either as a flake ice machine or a block ice machine.
- Hydraulically activated system
- One-man operation

Block ice size: 15 x 15 x 30 cm. 5kg
Block ice size: 20 x 20 x 50 cm. 15kg.
Block ice size: 25 x 25 x 50 cm. 23kg.

MODEL PRICE

To see the price please Login or Register.

Get Your Bid

TECHNICAL INFORMATION

Model Name
BLOCK-CP 15 Ts
Flake Ice Capacity (Per Day)
15000 kg/24h
Block Ice Capacity (Per Day)
652 pieces
Block Ice Capacity (Per Hour)
27 pieces
Block Ice Size
25x25x48 cm
Block Ice Weight
23 kg
Cooling Capacity
100600 watt
Compressor Displacement
308,8 m3/h
Compressor Type
Semi Hermetic
Compressor Power
2x40 HP
Compressor Electric Power
54,8 kw/h
Compressor Absorbed Current
95 Amp
Refrigerants
R404
Dimensions (WxLxh)
2150x4700x4750 mm.
Ice Discharge Outlet Size
1277 mm
Hydraulic Engine Motor Power
5,5 Kw.
Water Type
Fresh Water
Water Inlet Temperature
20 ℃
Outside Temperature
43 ℃
Condensation Temperature
33 ℃
Evaporation Temperature
-22 ℃
Ice Thickness
1,8 - 2,2 (Flake) mm
Required Water Pressure
1 bar
Weight
~5100 kg
Energy
380V/50Hz/3Ph
