SFM 200

Flake Ice Machine (Sea Water)

ABOUT PRODUCT

Termodizayn on board type ice machines can tolerate shake and wobble of the fishing boats and are specifically designed to withstand marine conditions which causes corrosion. Produces ice with sea water and it’s condenser is also cooled with sea water.

- Ice generator with water-cooled condenser as standard, also available as optional with air-cooled condenser.
- Including control panel and sea water pump
- Ice blade and Ice generator drum are made of stainless steel
- Chassis is made of stainless steel - Fitted with semi-hermetic or screw compressors.
- Refrigerant R404a, R507a or R22
- High condenser and fan capacities are tested under extreme conditions.

MODEL PRICE

To see the price please Login or Register.

Get Your Bid

TECHNICAL INFORMATION

Model Name
SFM 200
Ice Capacity (Per Day)
20000 kg/24h
Ice Capacity (Per Hour)
832 kg/h
Cooling Capacity
112037 watt
Compressor Displacement
489.56 m3/h
Compressor Power
2x80 HP
Compressor Electric Power
65,9 kw/h
Compressor Absorbed Current
135,4 Amp
Compressor Type
Semi Hermetic
Condenser Type
Water Cooled (Sea Water)
Evaporator Type
Vertical Drum
Refrigerants
R404a - R449a
Dimensions (WxLxh)
1700 x 5000 x 2500 mm.
Ice Discharge Outlet Size
1450 mm
Required Pump Flow
49,5 m3/h
Chassis
Cr.Ni Stainless Steel Chassis
Water Type
Sea Water
Outside Temperature
45 ℃
Condensation Temperature
40 ℃
Evaporation Temperature
-28 ℃
Ice Thickness
1,8 - 2,2 mm
Required Water Pressure
1 bar
Weight
3800 kg
Energy
380V/50Hz/3Ph
