SCR-SILO-1000

Ice Silos

ABOUT PRODUCT

Ice storage with rake system:
With a full automatic rake system, certain amounts of ice can be stored over a period and discharged on demand and for covering demand peaks. An entire daily capacity of the ice plant can be discharged during the production in a short period. Even excess production capacity will fill the ice storage and is not lost.

The Mobile Ice Storages are equipped with fully automatic rake and conveyor system as well as a air cooling unit. They are prefabricated in rigid steel frames or a container with double-wall insulation.

The size of the ice storage depends on its holding capacity but starts with a 10-ft. container up to a 40-ft. container. Termodizayn provides support steel frames, stairs and platforms for all ice storage sizes. After finalizing the connection of power and water supply together with the installation of the ice plant, the ice storage and delivery system are ready to use.
Ice storage with screw system:
Termodizayn semi-automatic screw systems are installed in 10-ft. containers up to a 40-ft. container, including an insulated storage room, leveling screw and air cooling unit. The ice storage can be transported like a standard container on a truck.

The ice storage is filled automatically and the ice is distributed evenly in the container via a screw. The ice discharge is carried out manually via an open trough discharge screw. This is the most economical way of storing flake ice.

MODEL PRICE

To see the price please Login or Register.

Get Your Bid

TECHNICAL INFORMATION

Model Name
SCR-SILO-1000
Type
Screw
Internal Volume
1000 Lt.
Motor power
1,11 kw
Screw Material Type
Inox
Dimensions (WxLxh)
800x1900x2500 mm
Tires
Optional
Working Temperature
-5 ℃
Control Panel
Include
Energy
380V/50Hz/3Ph
Absorbed Current
3,6 Amp

WORKING CONDITIONS

Energy
380V - 50Hz - 3Ph
