MBF 20

Mobile Blast Freezer

ABOUT PRODUCT

THERMODESIGN advices the container type freezing tunnel because it is portable, you can put where you want, or you can rent it, to be portable gives you many advantages. You can use your garden from where you can win or loading in factory where cover is provided.

Mounting and dismounting of the fixed type panel can be quite costly cold storage is also deformed into multiple disassembly, so many business owners and especially fishing companies prefer portable container type cold storages. Plenty of time and places where fishing (in ports) is very convenient to use.

THERMODESIGN portable container type is according to the international transportation freezing systems, there is no standard container sizes except projection machine thus providing ease of transport.

Sea countries for the excessive production of special sizes are possible. Especially into standard sea freight containers in order to bring down the high transport rates are specifically designed to fit the dimensions.

What transition range on the panel door isolation 100cm.x190cm. What is transitive. PVC coated surface material appearing galvalum insulation panels of sheet metal.

On the refrigerator it can operate smoothly even in the desert type tropical conditions. Dual-stage compressors are special deep-cooling compressor.

MODEL PRICE

To see the price please Login or Register.

Get Your Bid

TECHNICAL INFORMATION

Model Name
MBF 20
Temperature Range
+20/-40 ℃
Product Inlet Temperature
+10 ℃
Freezing Amount (8h)
1170 kg/8h
Freezing Amount (12h)
1755 kg/12h
Freezing Amount (24h)
3510 kg/24h
Product Type
Fish (Medium Size)
Efective Loading Area
208x300 cm
Fish Bin Quantity (max)
280
Cooling Capacity
17550 watt
Compressor Type
Double Stage Semi Hermetic
Compressor Power
20 HP
Compressor Electric Power
12,7 kw/h
Compressor Absorbed Current
27,1 Amp
Compressor Displacement
71 m3/h
Refrigerants
R404
Door Type
Hinged Pvc+Pvc
Door Crossing Dimensions
110x180 cm
Insulation Type
Sandwich Panel
Panel Surface
PVC
Floor Surface Metarial
Playwood + 2mm Cr.Ni
Dimensions (WxLxh)
2430x6058x2591 mm
Chassis
20ft Container
Weight
~4000 kg

WORKING CONDITIONS

Energy
380V - 50hz - 3Ph
Outside Temperature
33 ℃
Evaporation Temperature
-40 ℃
Condensation Temperature
43 ℃
