F100 B

Flake Ice Machine (Fresh Water)

ABOUT PRODUCT

Produces flake ice using regular fresh water. Does not require treated water. - Operates smoothly under tropical conditions. - Always quiet and highly efficient. - Produces hygienic ice thanks to it’s vertical type ice evaporator drum
- 24/7 non-stop operation.
- All equipments comply with EU standards.
- Ice generator with air-cooled condenser as standard, also available as optional with water-cooled condenser.
- and optionally salt dosaging pump.
- Ice blade and Ice generator drum are made of stainless steel.
- Chassis is made of anti-corossive painted steel.
- High condenser and fan capacities are tested under extreme conditions.

MODEL PRICE

To see the price please Login or Register.

Get Your Bid

TECHNICAL INFORMATION

Model Name
F100 B
Ice Capacity (Per Day)
10000 kg/24h
Ice Capacity (Per Hour)
422 kg/h
Cooling Capacity
50300 watt
Compressor Displacement
154,4 m3/h
Compressor Power
40 HP
Compressor Electric Power
26,8 kw/h
Compressor Absorbed Current
46,5 Amp
Compressor Type
Semi Hermetic
Condenser Type
Air Cooling
Evaporator Type
Vertical Drum
Refrigerants
R404a
Dimensions (WxLxh)
1500x3380x1850 mm
Ice Discharge Outlet Size
920 mm
Weight
2170 kg
Energy
380V/50Hz/3Ph

WORKING CONDITIONS

Water Inlet Temperature
20 ℃
Outside Temperature
33 ℃
Condensation Temperature
45 ℃
Evaporation Temperature
-21 ℃
Ice Thickness
1,8 - 2,2 mm
Required water pressure
1,5 bar
Water Type
Fresh Water
